Edgecore ECS4510-28T managed network switch

The Edgecore ECS4510-28T managed network switch. Key Specifications Brand: Edgecore Networks Model: ECS4510-28T Type: Layer 2 / Layer 3 Lite Managed Switch Ports: 24 × 10/100/1000 Mbps RJ45 Gigabit ports 2 × Gigabit SFP uplink ports 1 × Console port 1 × USB port Switching Capacity: 56 Gbps Forwarding Rate: 41.66 Mpps MAC Address Table: 16K entries Jumbo Frame Support: Up to 9 KB VLAN Support: 4K VLANs (802.1Q) Stacking: Up to 8 units Management & Features Web GUI, CLI, Telnet, SNMP v1/v2c/v3 Static Routing, RIP, VRRP ACL, 802.1X, DHCP Snooping, IP Source Guard, DoS Protection Link Aggregation: 802.3ad LACP STP/RSTP/MSTP support IGMP Snooping v1/v2/v3, MLD Snooping QoS with 8 priority queues per port Physical Details Power Supply: 100–240V AC Maximum Power Consumption: 20W Dimensions: 440 × 207 × 44 mm Weight: Approx. 3.1 kg Operating Temperature: 0°C to 45°C Typical Use Cases Enterprise LANs Office/core switching VLAN segmentation CCTV/IP surveillance networks Small datacenter or server rack deployments
